型式Model
|
ON-688CDII
|
ON-688CDDII
|
檢測探頭Detecting Tower
|
單探頭Single head
|
雙探頭Twin head
|
電源電壓Voltage
|
1P AC220V 50/60Hz
|
電源功率Rate
|
<140W
|
200W
|
檢測通道寬度Detective Width(mm)
|
600mm
|
檢測通道高度Detective Height(mm)
|
100mm
|
標準檢驗塊、鋼球規格
Detective capability of Iron ball (mm)
|
Φ1.0
|
敏感度調節Sensitivity Adjustment
|
1-10級連續可調Level steps
|
輸送帶速度Speed of conveyor
|
30m/min
|
探測方式Detection Method
|
磁性感應 Detected by magnet
|
報警方式Alarm
|
電子蜂鳴器鳴響,輸送帶停止或倒送、發光燈示 Automatic buzzer and alarm lamp, the conveyor will stop or return.
|
機器尺寸L×W×H Dimensions
|
1650×1040×920mm
|
2230×900×1050mm
|
裝箱尺寸L×W×H Packing Volume
|
1850×1200×1150mm
|
2350×1300×1150mm
|
凈重/毛重N.W / G.W
|
220/320kgs
|
330/520kgs
|
